Aluminum Composite Panel Cutting/Grooving Machine

Aluminum Composite Panel Cutting/Grooving Machine LMX–1600

Main specification and technical parameter

1.Power supply：    Made to order
2.Cutting motor power：  2.2KW
3.Motor rotary speed： 2850r/min
4.Cutting width： max 4100mm
5.Cutting height：max 1600mm
6.Milling cutter size： φ250mm×16mm×φ30mm  (92&135°)     Z=12
                       φ250mm×φ30mmX3.2  (saw blade cut off)     Z=80
7.Cleaner motor power: 2.2KW

Equipment Processing accuracy：

1.Groove linear in horizontal milling： ≤0.25/1000mm;
2.Groove linear in vertical milling： ≤0.25/1000mm;
3.Cutting surface roughness：Ra12.5∪m
4.Two IS vertical slots max deviation from standard line ≤1;
5.The parallelism of two milling slots in the same direction ≤0.25/1000mm

Equipment features:

1.Milling cutters can work in horizontal and vertical way
2.There is pulling device at the bottom and middle position which is convenient for the different size processing;
3.The interval subsection orientation device and the lock device are set in the movable frame;
4.Used for milling processing of the profile bending parts of aluminum curtain wall;
5.Processing range (L×H): 4100×1600mm;
6.The slot depth can be adjusted for the special designed cutters
